Built on two distinct platforms that include ten models covering a power range from 205 to 445 horsepower, the Claas Axion 900 and Axion 800 series deliver premium performance with advanced technology designed to streamline workflows and optimize productivity while reducing operating costs
Technology That Works for You
In today’s world, leveraging smart technology is essential. But innovation only makes a difference when it’s accessible and enhances everyday work. That’s why Claas designs its high-horsepower tractors to simplify complex agricultural tasks. Both the Axion 900 and Axion 800 series reflect this trend, integrating intelligent solutions that accelerate field operations and improve efficiency for a wide range of farming needs.
Axion 900: Built for Contractors and Large-Scale Operations
The Axion 900 series is engineered for the toughest jobs—from deep soil tillage to hauling heavy trailers—thanks to a long wheelbase (3.15 meters) and a robust weight of over 13 tons. These machines are ideal for contractors and large-scale farms looking for high performance and endurance.
Axion 800: Versatility for Medium-Sized Farms
Targeted at medium-sized farms, the Axion 800 series offers a perfect balance of power, versatility, and user-friendliness. Compact dimensions (under 3 meters in wheelbase and less than 10 tons in weight) make these tractors ideal for mixed farming applications, including planting, spraying, and transport.
Smart Farming with CEMOS and CTIC
To maximize efficiency, both series can be equipped with:
- CEMOS: Claas’s award-winning AI-powered driver assistance system, which offers real-time recommendations on engine, transmission, and hydraulic settings based on field conditions. It also suggests optimal ballast and tire pressure for the best traction and fuel efficiency.
- CTIC: The central tire inflation control system, which continuously adjusts tire pressure to match working conditions, helping reduce soil compaction and fuel consumption.
These systems contribute to a reduction in fuel use by up to 12% and an increase in productivity per hectare of up to 11%.
Transmission Options for Every Need
Both series offer advanced CVT “CMATIC” transmissions (standard on Axion 900, optional on Axion 800), combining a hydrostatic unit with an electronically controlled mechanical gearbox. These allow:
- Road speeds up to 50 km/h at 1,600 rpm
- Four mechanical work ranges for optimal fuel efficiency
- Decoupled engine speed, travel speed, and power output for maximum performance and minimal consumption
The Axion 800 models also offer “Hexashift” powershift transmissions (except the Axion 870, which uses CMATIC only), with 24 forward and 24 reverse gears and programmable electrohydraulic reversing (Revershift) for smooth operation under load.
Engine Performance: NEF and Cursor Series
- Axion 800 series: Powered by 6.7-liter NEF engines from FPT Industrial, with maximum power from 205 to 280 hp (up to 295 hp with Claas Power Management).
- Axion 900 series: Equipped with 8.7-liter Cursor engines, delivering 325 to 445 hp.
All engines feature:
- High-pressure common rail (1,800 bar)
- 4-valve cylinder heads
- Fixed or variable geometry turbochargers
- Electronically controlled cooling systems
- SCR-only emissions control (no EGR), cutting fuel consumption and meeting the latest emission standards.
Hydraulics and PTO for Demanding Applications
- Axion 800: Load-sensing hydraulics with 110 L/min standard (optional 150 L/min), up to 7 spool valves, rear lift capacity of 12.2 tons, and front lift of 5.6 tons.
- Axion 900: Over 220 L/min, up to 8 spool valves, rear lift up to 11.2 tons, front up to 6.5 tons.
PTO speeds include 540/1,000 rpm for the Axion 800 and 740/1,000 rpm for the Axion 900—ideal for a wide range of implement requirements.
Axion 900 Terra Trac: Tracked Power, Reduced Soil Compaction
Two models from the Axion 900 series—the Axion 930 and Axion 960—are also available in Terra Trac versions, featuring Claas’s unique suspended track system adapted from their high-performance forage harvesters.
Key benefits:
- 15% more traction
- 35% larger contact area
- 50% less ground pressure
- Maintains full road mobility (under 3 meters wide)
- Top speed of 40 km/h
- Hydro-pneumatic suspension for smooth ride
- Track pivoting range of 8 to 15 degrees for optimal ground contact
Why Choose Claas Axion 800 and 900
These high-horsepower open-field tractors are built to meet the demands of modern agriculture—combining intelligent automation, power, comfort, and flexibility. Whether you’re a contractor, a large enterprise, or a progressive medium-sized farm, the Claas Axion 800 and 900 series provide unmatched performance, reliability, and cost-efficiency.
